Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They manufacture equipment such as manlifts, boom lifts and aerial lifts. These equipments are designed to facilitate access to hard to reach areas, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains handholds or platforms or steps that are attached to the unit to be able to move personnel from each floor.
TB85
Terex's TB85 man lift offers a max working height at 91 feet. The platform's max height reaches 85 feet, while the maximum width of the model is 8.5 feet. The TB85 has dimensions that measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
